Description
Specifications
Air Filter
Heavy-duty canister air filtration system
Blade Spindles
No maintenance, sealed and non-greasable spindles; 7.75″-diameter cutter housing with 30mm (1.18″) diameter spindle shaft and splined blade driver.
Blade Tip Speed
Approximately 18,500 fpm.
Blades
3 Blades at 20.50″ Length
Carb Compliant
No
Caster Forks
.50″ thick caster yoke arms.
Cutting Heights
1.0″ (2.5 cm) to 5.5″ (11.8 cm) in 0.25″ (0.64 cm) increments adjustable from operators seat.
Deck Construction
10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.
Deck Lift
Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.
Deck Style
Floating Deck
Deck Style Description
Full-floating UltraCut Series 6 with heavy-duty spindle. Side discharge standard with the option to bag or mulch.
Drive
Hydro-Drive
Drive Description
Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 16 cc pumps and 17.1 cubic inch motors.
Drive Tires
24 x 12.0-12, 4-ply Turf Master
Drive Wheel Release
Allows unit movement without engine running.
Electrical
12-volt battery with 25-amp alternator.
Front Caster Tires
13 x 6.5-6, smooth-tread, semi-pneumatic.
Fuel Capacity
12-gallon (45.4-L), single fuel tank with single fill location.
Fuel Indicator
Yes – electronic Sender
Fuel System
Electronic Fuel Injected
Height
70 in. (177.8 cm)
Length
86.1 in. (218.7 cm)
Onboard Intelligence
RED Technology
Parking Brake
Lever-actuated disc brake.
ROPS
2-post foldable ROPS standard with seat belt and latch.
Safety Package
Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.
Seat
Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
Speed
Infinitely variable speed selection from 011.5 mph (18.5 kmph) forward, 06.0 mph (11.3 kmph) reverse
Standard Features
Engine hour meter and cup holder
Starter
Electric
Steering Control
Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
