Description
SmartlockPro Standard Duplex GFCI Receptacle, 125 VAC, 20 A, 10 kA Short Circuit, 2 Pole, 3 Wires, 14 to 10 AWG Wire, Self-Grounding Grounding, NEMA 5-20R, 1250 VAC Dielectric, Back, Side Wired Terminal, Polycarbonate Body, Brass Contact, White, -35 to 66 deg C, Additional Information: Zinc-Plated Steel Yoke, Plated Steel Terminal, Thermoplastic Face, 14 to 18 in-lb Torque, 1 hp, Galvanized Steel Strap
Features:
- Provides continuous ground fault protection detects and trips on actual ground fault even when self-test is being conducted
- On initial power up, tests the GFCI within 3 s
- Auto-monitoring exceeds the UL requirement
- Auto adapts and shifts to more frequent testing if potential problem is detected
- Status indicator light provides simple, intuitive feedback on power and protection status as well as indication of line/load reversal
- Patented lockout action prevents reset if GFCI is damaged and cannot respond to a ground fault
- Electronics are designed to minimize any false triggers
- Reduced depth makes it easier to install in any electrical box, even shallow ones
- Terminals allow for easy wiring options back and side wire capable
- External back wire clamps provide visual indication of proper wire seating
- Withstands high torque and resists wire pullout
- Standard brass self-grounding clip
- Trip threshold meets or exceeds UL requirements for tripping time
- Improved immunity to high frequency noise reduces nuisance tripping
- Advanced electronics design provides superior resistance to electrical surges and over voltages
- Compatible with all Decora devices and wallplates
Other Attributes:
- SKU: 3533080
- Voltage Rating: 125
- Amperage Rating: 20
- Short Circuit Rating: 10
- Number of Poles: 2
- Number of Wires: 3
- Wire Size: 14 to 10
- Grounding: Self-Grounding
- NEMA Rating: NEMA 5-20R
- Dielectric Strength: 1250
- Terminal Type: Back, Side Wired
- Body Material: Polycarbonate
- Contact Material: Brass
- Color: White
- Temperature Rating: -35 to 66
- Additional Information: Zinc-Plated Steel Yoke, Plated Steel Terminal, Thermoplastic Face, 14 to 18 in-lb Torque, 1 hp, Galvanized Steel Strap
Documents:
Technical Bulletin
Instruction/Installation Manual
