Description
That sounds like a great offering from Renogy! Their Renogy Custom Kits provide a convenient solution for individuals looking to create a solar power system tailored to their specific needs. Whether it’s for residential use, RVs, boats, or off-grid cabins, Renogy offers a comprehensive range of options to suit different lifestyles.
One of the key advantages of Renogy Custom Kits is that they eliminate the need to search for compatible components from multiple sources. Everything required for the solar power system is conveniently packaged together, ensuring a seamless integration of solar panels, controllers, batteries, inverters, and other necessary accessories.
In terms of solar panel options, customers can choose between 2 pieces of 100W classic rigid solar panels or 1 piece of 200W classic rigid or ultra-flexible solar panels. For charge controllers, the kits come with either a 20A MPPT charge controller from the classic Rover series or a 30A PWM charge controller.
Regarding batteries, customers have the choice of no battery included or 2 pieces of 100Ah smart lithium batteries with a self-heating feature. Alternatively, there is an economical lithium battery option available, which comes with built-in Bluetooth functionality.
The kits also provide flexibility for inverters. Customers can opt for no inverter or choose a 1000W pure sine wave inverter. Another option is the inverter charger, which combines the functions of an inverter and a charger.
Additionally, Renogy includes all the necessary accessories such as cables, connectors, mounts, and monitoring equipment to connect the chosen components. This ensures a comprehensive and hassle-free solar power system installation experience.
Finally, it’s worth noting that the average peak sun hours for the areas where the kits are likely to be used is around 5-6 hours. This information helps users estimate the potential solar energy generation they can expect from the system.
Overall, Renogy Custom Kits offer a convenient, all-in-one solution for individuals looking to harness solar power for their specific needs, providing flexibility, compatibility, and ease of installation.
Specifications
| Solar Panel | Quantity*Title |
|---|---|
| 2*100W 12V Rigid Solar Panel | |
| 1*200W 12V Rigid Solar Panel | |
| 1*200W 12V Flexible Solar Panel | |
| Charge Controller | Quantity*Title |
| 1*Wanderer Li 30A PWM W/ LCD & BT1 Module | |
| 1*Adventurer Li- 30A PWM W/ LCD & BT1 Module | |
| 1*Voyager 20A PWM Waterproof | |
| 1*Rover 20A MPPT W/ LCD & BT1 Module | |
| Battery | Quantity*Title |
| 2*12V 100Ah LiFePO4 Battery W/ Bulit-in Bluetooth | |
| 2*12V 100Ah Self-Heating LiFePO4 Battery W/ BT2 Module | |
| 2*Battery Inverter Cables | |
| Inverter | Quantity*Title |
| 1*1000W 12V Pure Sine Wave Inverter | |
| Accessory Set/Basic | Quantity*Title |
| 2*Solar Panel Mounting Z Bracket — Set of 4 | |
| 1*Solar Y Branch Connectors MMF+FFM Pair(100W Solar Panel) | |
| 1*Solar Panel to Charge Controller Adaptor Kit | |
| 1*Battery to Charge Controller Tray Cables | |
| Accessory Set/Premium | Quantity*Title |
| 4*Solar Panel Mounting Z Bracket — Set of 4 | |
| 1*Solar Y Branch Connectors MMF+FFM Pair(100W 12V Rigid Solar Panel) | |
| 1*Solar Panel to Charge Controller Adaptor Kit | |
| 1*Battery to Charge Controller Tray Cables | |
| 1*BT-1 Bluetooth Module (New Version) | |
| 1*Holder w/ Fuse | |
| 1*ANL Fuse Set w/ Fuse | |
| 1*Terminals for 3/8 in Lugs |
100W 12V RIGID SOLAR PANEL
Max Power at STC:100W
Open Circuit Voltage:24.3V
Short Circuit Current:5.21A
Optimum Operating Voltage:20.4V
Optimum Operating Current:4.91A
Operating Temperature:-40F to 176F
Maximum System Voltage:600V DC (UL)
Maximum Series Fuse Rating:15A
Dimensions:41.8 x 20.9 x1.38 in
Weight:14.1lbs/6.4kg
200W 12V RIGID SOLAR PANEL
Max Power at STC:200W
Open Circuit Voltage:23V
Short Circuit Current:11.05A
Optimum Operating Voltage:19.2 V
Optimum Operating Current:10.42 A
Operating Temperature:-40F~194F / -40~90
Maximum System Voltage:600 VDC UL
Maximum Series Fuse Rating:20A
Dimensions:58.7 x 27.5 x 1.38 in / 1491 x 699 x 35mm
Weight:26.46 lb (12 kg)
200W 12V FLEXIBLE SOLAR PANEL
Maximum Power at STC:200W
Open-Circuit Voltage (Voc):23.9V
Short Circuit Current:10.74A
Optimum Operating Current (Imp):10.02A
Maximum System Voltage:600V DC
Maximum Series Fuse Rating:15A
Operating Temperature:-40F to 176F (-40C to +80C)
Dimensions:1605 x 748 x 3 mm (63.2 x 29.4 x 0.1 in)
Weight:4.9 kg / 10.8 lbs
ROVER 20A MPPT W/ LCD & BT1 MODULE
Nominal Voltage:12/24V Auto-Detect
Rated Charge Current:20A
Max. PV Input Power:12V/260W, 24V/520W
Max. PV Input Voltage:95 VDC
Operating Temperature:-35C to 45C; -31F to 113F
Dimensions:210 x 151 x 68 mm; 8.27 x 5.95 x 2.69 in
Weight:3.1 lbs / 1.4 kg
WANDERER LI 30A PWM W/ LCD & BT1 MODULE
Nominal System Voltage:12 VDC
Rated Charge Current:30A
Max. PV Input Power:25 VDC
High Voltage Disconnect:16V
Operating Temperature Range:-31F – 176F
Dimensions:6.45 x 4.31 x 1.76 inches
Weight:0.65 lbs
ADVENTURER LI- 30A PWM W/ LCD & BT1 MODULE
Nominal Voltage:12 VDC/ 24 VDC
Rated Charge Current:30A
Max. PV Input Voltage:50 VDC
Max. PV Input Power:12V(400W) / 24V(800W)
Storage Temperature:-31F to 176F
Dimensions:6.56 x 4.50 x 1.90 inches
Weight:0.6 lbs
VOYAGER 20A PWM WATERPROOF
Nominal System Voltage:12/24V
Rated Charge Current:20A
PV Input Voltage Range:15V-55V
Max. Pv Open Circuit Voltage:12V@25V 24V@55V
Max. PV Input Power:12V @ 260W / 24V@520W
Operating Temperature Range:-31F – 113F
Dimensions:6.08*3.83*1.40 in
Weight:0.55Ibs
12V 100AH LIFEPO4 BATTERY W/ BULIT-IN BLUETOOTH
Battery Type:Lithium Iron Phosphate
Rated Capacity:100 Ah
Nominal Voltage:12.8 V
Voltage Range:10~14.8 V
Cycle Life(0.5C,25):80%DOD 2000 Cycles
Connection Method:Parallel(Up to 8)
Protection Rate:IP65
Charge Voltage:14.4V
Maximum Continuous Charging Current:50 A
Maximum Continuous Discharging Current:100 A
Standard Operation Temperature:255
Charge Temperature:32~131F/ 0~55C
Discharge Temperature:-4~140F/ -20~60C
Communication Port:Modbus
Built-in Bluetooth:Yes
Dimensions:12.99 x6.77 x 8.43 inch / 330 x 172 x 214mm
Weight:28.7 lbs. / 13.0 kg
12V 100AH SELF-HEATING LIFEPO4 BATTERY W/ BT2 MODULE
Battery Type:Lithium Iron Phosphate
Rated Capacity:100AH
Nominal Voltage:12.8 V
Cycle Life(0.2C,25):80%DOD 4000 Cycles
Connection Method:Parallel
Protection Rate:IP54
Charge Voltage:14.4V
Maximum Continuous Charging Current:50 A
Maximum Continuous Discharging Current:100 A
Automatically Self-heating Function:Temperature <415
Standard Operation Temperature:255
Storage Temperature:-13~149 / -25~65
Communication Port:RJ45 (RS485 Protocol)
Built-in Bluetooth:No
Dimensions:11.4 x 6.8 x 7.4 inch / 289 x 172 x 187.5 mm
Weight:26 lbs. / 11.8 kg
1000W 12V PURE SINE WAVE INVERTER
Continuous Output Power:1000W
Peak Power Rating:2000W
