Description
Meet heavy commercial air requirements with the EMAX 10HP 80-Gallon Vertical Compressor to supply high-output pneumatic volume to drive multiple industrial manufacturing machines and multi-bay automotive service tools. The 10 HP commercial motor drives a solid cast-iron 2-stage pump producing 38 CFM at 100 PSI and 34 CFM at 175 PSI across an 80-gallon vertical ASME receiver. Commercial mechanics run 1-inch impact wrenches and sanders without line pressure drops. The unit requires dedicated 230V 1-phase 42-amp wiring.
Two-Stage High-Pressure Bench Limits
Pneumatic bench testing proves actual delivered air output measures 38 CFM at 100 PSI and 34 CFM at 175 PSI, supporting six commercial technicians cycling heavy air tools simultaneously. Initial tank fill from zero to 175 PSI completes in 185 seconds, with recovery cycle time from 135-PSI cut-in to 175-PSI cut-out clocking at 38 seconds. Running at a low 640 RPM, cast-iron pump cylinder head temperatures stabilize at 170 degrees Fahrenheit during multi-hour testing runs in 90-degree ambient conditions.
Solid ASTM Class 30 cast iron forms the 2-stage pump block, crankcase, and deep-finned cylinder head, delivering superior thermal heat dissipation and long valve service life. An automotive-style balanced crankshaft turns inside heavy-duty roller bearings, supported by full splash lubrication. A high-efficiency finned copper intercooler drops air temperatures between compression stages, preventing moisture flash vapor. Sized for permanent shop installation, the bare vertical air compressor weighs 740 lbs, measuring 38x32x76 inches.
Key Features of EMAX H10V080V1-STD
Manufacturing plant engineers and commercial auto repair shops buy EMAX 10HP 80-Gallon Vertical Compressors to supply dependable high-CFM air to production machinery. Compare commercial 10 HP stationary air compressor pricing to upgrade your shop pneumatic air supply.
- Solid 100-percent cast-iron 2-stage pump delivers 34 CFM at 175 PSI, running cool at 640 RPM for long commercial service life.
- Heavy-duty 10 HP electric motor provides continuous-duty power with commercial NEMA-rated magnetic starter protection cleanly.
- ASME-certified 80-gallon vertical pressure vessel stores large air buffers, dampening pressure spikes during heavy demands cleanly.
- Finned copper intercooler drops compressed air temperatures to reduce condensation buildup in shop air drops cleanly.
- Industrial Swedish stainless steel disc valves resist heat deformation and carbonization, ensuring long maintenance intervals cleanly.
Automotive Fleet Negative Selection Filter
The elevated oil sight glass allows instant daily checks of pump oil level and clarity before shift startups. Do not purchase this high-output 10 HP compressor for small home garages with 100A main electrical panels, mobile truck mounting without high-output generators, or applications requiring oil-free breathable air lines. Routine care calls for draining tank moisture daily through the bottom ball valve, checking drive belt tension every 500 operating hours, and changing synthetic compressor oil every 1000 operating hours.
Factory Warranty Hardware Manifest
EMAX covers this 10 HP vertical compressor with a 5-Year limited warranty on major components, extendable to a Lifetime pump warranty upon using factory synthetic oil maintenance kits. The factory shipment crate includes one 80-gallon vertical air compressor, pre-wired magnetic starter, belt guard, and comprehensive technical service manual.
