Description
Advance Electronic Ballast, Series: Centium Slimline Series, Fluorescent Lamp, 75 W Lamp Wattage, 132 to 135 W Input Wattage, 120 to 277 V, 0.48 to 1.13 A, 50/60 Hz, Instant Start, 0 deg F Minimum Starting Temperature, 10 % Total Harmonic Distortion (THD), 0.99 Power Factor, 1 Lamps, 1.6 Crest Factor, 0.88 Ballast Factor, 1.24 Ballast Efficacy Factor (B.E.F), 0.1 s Ignition Time, 18 AWG Wire, Parallel Circuit, NEMA 410 Enclosure, Remote Mounting, Metal, 70 deg C, 9-1/2 in Length, 1.3 in Width, 1 in Height, Additional Information: F96T12 Lamp Type
Other Attributes:
- SKU: 3249430
- Series: Centium Slimline Series
- Lamp Type: Fluorescent
- Lamp Wattage: 75
- Input Wattage: 132 to 135
- Voltage Rating: 120 to 277
- Amperage Rating: 0.48 to 1.13
- Frequency Rating: 50/60
- Start Type: Instant
- Minimum Starting Temperature: 0
- Total Harmonic Distortion (THD): 10
- Power Factor: 0.99
- Number of Lamps: 1
- Crest Factor: 1.6
- Ballast Factor: 0.88
- Ballast Efficacy Factor (B.E.F): 1.24
- Ignition Time: 0.1
- Wire Size: 18
- Circuit Type: Parallel
- Enclosure Type: NEMA 410
- Mounting Type: Remote
- Material: Metal
- Temperature Rating: 70
- Length: 9-1/2
- Width: 1.3
- Height: 1
- Additional Information: F96T12 Lamp Type
Documents:
Specification Sheet
